Prysmian BICON Barr-PB Exd IIC Cable Gland (424TP Series) is a brass indoor and outdoor cable gland for use in Zone 1 and Zone 2 hazardous areas. Suitable for use with braid armoured cables.
Part Numbers: 424TP- 52, 424TP-53, 424TP-85*, 424TP-55, 424TP-86*, 424TP-56, 424TP-57, 424TP-89*, 424TP-59, 424TP-61, 424TP-63, 424TP-64, 424TP-02, 424TP-03, 424TP-35*, 424TP-05, 424TP-36*, 424TP-06, 424TP-07, 424TP-39*, 424TP-09, 424TP-11, 424TP-13, 424TP-14.
Prysmian 424TP Features
Brass indoor and outdoor cable gland for use in Zone 1 and Zone 2 hazardous areas.
Suitable for circular, galvanised steel single wire armour cables with extruded
polymeric oversheath and Lead inner sheath.
Achieves IP66 seal onto cable and to enclosure with suitable sealing washer or thread sealant.
Provides mechanical cable retention and electrical continuity through the armour wire termination.
Provides electrical continuity to the inner lead sheath.
Suitable for most climatic conditions – weatherproof and waterproof.
Standard and Nickel plated versions available.
Full Installation Instructions supplied.
Technical Data
Certified ΙΙ 2GD, Ex e ΙΙ & Ex d ΙΙC under ATEX directive 94/9/EC
Atex Compliance Standards: EN 60079-0, EN 60079-1, EN 60079-7, EN 61241-0, EN 61241-1
Certificate number Sira04ATEX1080X
IECEx Compliance Standards: IEC 60079-0, IEC 60079-1, IEC 60079-7, IEC 61241-0, IEC 61241-1
Certificate number IECEx SIR 10.0072X
Service temperature range –60°C to +90°C
Zones 0, 1 & 2 with Ex ia IIA, B & C equipment
Zones 1 & 2 with Ex ib IIA, B & C equipment
Zones 1 & 2 with Ex d IIA, B & C equipment with any volume
Zones 1 & 2 with Ex e II equipment
Zones 1 & 2 with Ex p II equipment
Zone 2 with Ex nA II equipment
Zone 2 with Ex nR II equipment
For more information on Prysmian BICON Barr-PB Exd IIC Cable Gland (424TP Series), please consult Datasheet below.
FREE Technical Advisory Service
E-Tech Components UK Ltd maintains a free technical advisory service.
Contact us for enquiries concerning this and all other products: +44 (0) 1744 762 929
| Design Ref. (Standard) | Design Ref. (Nickel Plated) |
|---|---|
| Design Ref. (Standard)424TP- 52 | Design Ref. (Nickel Plated)424TP-52V |
| Design Ref. (Standard)424TP-53 | Design Ref. (Nickel Plated)424TP-53V |
| Design Ref. (Standard)424TP-85* | Design Ref. (Nickel Plated)424TP-85V* |
| Design Ref. (Standard)424TP-55 | Design Ref. (Nickel Plated)424TP-55V |
| Design Ref. (Standard)424TP-86* | Design Ref. (Nickel Plated)424TP-86V* |
| Design Ref. (Standard)424TP-56 | Design Ref. (Nickel Plated)424TP-56V |
| Design Ref. (Standard)424TP-57 | Design Ref. (Nickel Plated)424TP-57V |
| Design Ref. (Standard)424TP-89* | Design Ref. (Nickel Plated)424TP-89V* |
| Design Ref. (Standard)424TP-59 | Design Ref. (Nickel Plated)424TP-59V |
| Design Ref. (Standard)424TP-61 | Design Ref. (Nickel Plated)424TP-61V |
| Design Ref. (Standard)424TP-63 | Design Ref. (Nickel Plated)424TP-63V |
| Design Ref. (Standard)424TP-64 | Design Ref. (Nickel Plated)424TP-64V |
| Design Ref. (Standard)424TP-02 | Design Ref. (Nickel Plated)424TP-02V |
| Design Ref. (Standard)424TP-03 | Design Ref. (Nickel Plated)424TP-03V |
| Design Ref. (Standard)424TP-35* | Design Ref. (Nickel Plated)424TP-35* |
| Design Ref. (Standard)424TP-05 | Design Ref. (Nickel Plated)424TP-05V |
| Design Ref. (Standard)424TP-36* | Design Ref. (Nickel Plated)424TP-36* |
| Design Ref. (Standard)424TP-06 | Design Ref. (Nickel Plated)424TP-06V |
| Design Ref. (Standard)424TP-07 | Design Ref. (Nickel Plated)424TP-07V |
| Design Ref. (Standard)424TP-39* | Design Ref. (Nickel Plated)424TP-39* |
| Design Ref. (Standard)424TP-09 | Design Ref. (Nickel Plated)424TP-09V |
| Design Ref. (Standard)424TP-11 | Design Ref. (Nickel Plated)424TP-11V |
| Design Ref. (Standard)424TP-13 | Design Ref. (Nickel Plated)424TP-13V |
| Design Ref. (Standard)424TP-14 | Design Ref. (Nickel Plated)424TP-14V |
