Prysmian BICON E1XF NPT Cable Gland (473NP Series) is a brass indoor and outdoor cable gland for use in hazardous locations. Suitable for use with all braid wire armoured cables.
Part Numbers: 473NP-03, 473NP-04, 473NP-07, 473NP-05, 473NP-08, 473NP-10, 473NP-14, 473NP-15, 473NP-20, 473NP-21, 473NP-27, 473NP-28, 473NP-32, 473NP-33, 473NP-38, 473NP-44, 473NP-45.
Prysmian 473NP Features
Brass indoor and outdoor cable gland for use in hazardous areas.
Suitable for circular, Braid steel wire armour cables with extruded polymeric bedding and oversheath.
Achieves IP66 seal onto cable and to enclosure with suitable sealing washer or thread sealant.
Three part armour lock provides mechanical cable retention and electrical continuity.
Inner PCP seal grips cable bedding and provides additional ingress protection.
Prysmian BICON 473NP Cable Gland is suitable for most climatic conditions – weatherproof and waterproof.
Standard and Nickel plated versions available.
Full installation instructions supplied.
*NPT Threaded glands are supplied as glands only.
**Other NPT sizes are available upon request.
Technical Data
Certified II 2GD, Ex e II & Ex d IIC under ATEX directive 94/9/EC.
Atex Compliance Standards: EN 60079-0, EN 60079-1, EN 60079-7, EN 61241-0, EN 61241-1.
Certificate number Sira 02ATEX3092X.
IECEx Compliance Standards: IEC 60079-0, IEC 60079-1, IEC 60079-7, IEC 61241-0, IEC 61241-1.
Certificate number IECEx SIR 10.0071X
Service temperature range -60°C to +90°C.
Zones 0, 1 & 2 with Ex ia IIA , B & C equipment.
Zones 1 & 2 with Ex ib IIA , B & C equipment.
Zones 1 & 2 with Ex e II equipment.
Zone 2 with Ex nA II equipment.
Zones 21 & 22 with Ex tD A21.
Zones 1 & 2 with Ex d IIC equipment not containing a source of ignition & with a volume less than 2000 cm3.
Zones 1 & 2 with Ex d IIA & Ex d IIB equipment not containing a source of ignition & with any volume.
Zone 1 with Ex d IIA & Ex d IIB equipment containing a source of ignition & with a volume less than 2000 cm.
Zone 2 with Ex d IIA & Ex d IIB equipment containing a source of ignition & with any volume.
Zone 2 with Ex nR II equipment.
For more information on Prysmian BICON E1XF NPT Cable Gland (473NP Series), please consult the Datasheet below.
FREE Technical Advisory Service
E-Tech Components UK Ltd maintains a free technical advisory service.
Contact us for enquiries concerning this and all other products: +44 (0) 1744 762 929
| Design Reference (Standard) | Design Reference (Nickel Plated) |
|---|---|
| Design Reference (Standard)473NP-03 | Design Reference (Nickel Plated)473NP-03V |
| Design Reference (Standard)473NP-04 | Design Reference (Nickel Plated)473NP-04V |
| Design Reference (Standard)473NP-07 | Design Reference (Nickel Plated)473NP-07V |
| Design Reference (Standard)473NP-05 | Design Reference (Nickel Plated)473NP-05V |
| Design Reference (Standard)473NP-08 | Design Reference (Nickel Plated)473NP-08V |
| Design Reference (Standard)473NP-10 | Design Reference (Nickel Plated)473NP-10V |
| Design Reference (Standard)473NP-14 | Design Reference (Nickel Plated)473NP-14V |
| Design Reference (Standard)473NP-15 | Design Reference (Nickel Plated)473NP-15V |
| Design Reference (Standard)473NP-20 | Design Reference (Nickel Plated)473NP-20V |
| Design Reference (Standard)473NP-21 | Design Reference (Nickel Plated)473NP-21V |
| Design Reference (Standard)473NP-27 | Design Reference (Nickel Plated)473NP-27V |
| Design Reference (Standard)473NP-28 | Design Reference (Nickel Plated)473NP-28V |
| Design Reference (Standard)473NP-32 | Design Reference (Nickel Plated)473NP-32V |
| Design Reference (Standard)473NP-33 | Design Reference (Nickel Plated)473NP-33V |
| Design Reference (Standard)473NP-38 | Design Reference (Nickel Plated)473NP-38V |
| Design Reference (Standard)473NP-44 | Design Reference (Nickel Plated)473NP-44V |
| Design Reference (Standard)473NP-45 | Design Reference (Nickel Plated)473NP-45V |
