Filoform A Frame – 120 x 120mm designed to partner with the Filoseal+HD and Filoseal+HD FIRE, in order to hold a seal where the space or structure will not allow fitting of a seal into the structure itself.
Up to 4 hours fire resistance in transit frames (single side)
Tested to BS EN1366-3 2009
Upto 2 bar Pressure Resistance
100Kg pulling Force on the cables when sealed
10xd at 45º, with 1 bar pressure bending test
Key Features
Filoform Frames A and B are modular in construction and assembled in almost any size required.
Made of 6mm zinc plated steel to give a longer life.
Use of Filoseal+HD FIRE in these frames has been tested to EN1366-3:2009 for a period of up to 4 hours on a standard installation.
Minimising the need for upfront design. With the offer of this style frame, we have performed all the tests we can on it to give you confidence in the system as a whole.
No need to get into complicated modular insert sizes as this system’s filling is Filoform’s widely approved Filoseal+HD and Filoseal+HD FIRE systems
Assembled around existing cable runs which minimises (or should that be eliminates) down time.
Frames are a worthy addition to the Filoseal+HD and HD FIRE ranges. They are a problem solver in the following situations:
Irregular openings in a wall – frame neatens the install.
Walls of a poorer quality – frame stops reliance of seal bonding to structure.
Ducts with too many cables – frame allows splaying of cables to obtain a proper seal.
You can neatly seal large cable runs, such as a riser.
The modularity of the frame is based around two opening sizes: 120 x 120mm (type A) or 120 x 240mm (type B) which somewhat follows the frame sizing of regular transit systems. Obviously, for a larger hole, a multi-opening can be build to suit the application.
Built frame size notation.
Filoform Frames of Type A (120 x 120 opening). For clarity, all frames are 120 wide, it is the height that changes. Frame types followed by an ‘xn’ notation means there are n number of openings horizontally in a row. Frame types followed by a ‘+type A or B’ notation mean the frames are stacked vertically on top of each other.
So a frame denoted A+A+A x8 means there are 24 openings in total of size A, in columns of 3 high 8 times over.
Filoform A Frame – Part Numbers
A x 1: 1 opening, 120 x 120
A x 2: 2 openings side by side, 120 x 120mm
A x 3: 3 openings side by side, 120x120mm
A x 4: 4 openings side by side, 120x120mm
A x 5: 5 openings side by side, 120x120mm
A x 6: 6 openings side by side, 120x120mm
A x 7: 7 openings side by side, 120x120mm
A x 8: 8 openings side by side, 120x120mm
A + A: 2 openings on top of each other 120x120mm
A + A x 2: 4 openings, 2 in a row x 2 high 120x120mm
A + A x 3: 6 openings, 3 in a row x 2 high 120x120mm
A + A x 4: 8 openings, 4 in a row x 2 high 120x120mm
A + A x 5: 10 openings, 5 in a row x 2 high 120x120mm
A + A x 6: 12 openings, 6 in a row x 2 high 120x120mm
A + A x 7: 14 openings, 7 in a row x 2 high 120x120mm
A + A x 8: 16 openings, 8 in a row x 2 high 120x120mm
A + A + A: 3 openings on top of each other 120x120mm
A + A + A x 2: 6 openings, 2 in a row x 3 high 120x120mm
A + A + A x 3: 9 openings, 3 in a row x 3 high 120x120mm
A + A + A x 4: 12 openings, 4 in a row x 3 high 120x120mm
A + A + A x 5: 15 openings, 5 in a row x 3 high 120x120mm
A + A + A x 6: 18 openings, 6 in a row x 3 high 120x120mm
A + A + A x 7: 21 openings, 7 in a row x 3 high 120x120mm
If you’re unsure which part number to choose, just provide the hole size and an estimate of the cable quantities and sizes. We can work out your needs based upon this and provide a CAD based drawing of our solution.
For Additional Information on Filoform A Frame – 120 x 120mm, please refer to Technical Data Table or PDF File.
FREE Technical Advisory Service
E-Tech Components UK Ltd maintains a free technical advisory service.
Contact us for enquiries concerning this and all other products: +44 (0) 1744 762 929
| A x 1: 1 opening, 120 x 120 | |
|---|---|
| A x 2: 2 openings side by side, 120 x 120mm | |
| A x 3: 3 openings side by side, 120x120mm | |
| A x 4: 4 openings side by side, 120x120mm | |
| A x 5: 5 openings side by side, 120x120mm | |
| A x 6: 6 openings side by side, 120x120mm | |
| A x 7: 7 openings side by side, 120x120mm | |
| A x 8: 8 openings side by side, 120x120mm | |
| A + A: 2 openings on top of each other 120x120mm | |
| A + A x 2: 4 openings, 2 in a row x 2 high 120x120mm | |
| A + A x 3: 6 openings, 3 in a row x 2 high 120x120mm | |
| A + A x 4: 8 openings, 4 in a row x 2 high 120x120mm | |
| A + A x 5: 10 openings, 5 in a row x 2 high 120x120mm | |
| A + A x 6: 12 openings, 6 in a row x 2 high 120x120mm | |
| A + A x 7: 14 openings, 7 in a row x 2 high 120x120mm | |
| A + A x 8: 16 openings, 8 in a row x 2 high 120x120mm | |
| A + A + A: 3 openings on top of each other 120x120mm | |
| A + A + A x 2: 6 openings, 2 in a row x 3 high 120x120mm | |
| A + A + A x 3: 9 openings, 3 in a row x 3 high 120x120mm | |
| A + A + A x 4: 12 openings, 4 in a row x 3 high 120x120mm | |
| A + A + A x 5: 15 openings, 5 in a row x 3 high 120x120mm | |
| A + A + A x 6: 18 openings, 6 in a row x 3 high 120x120mm | |
| A + A + A x 7: 21 openings, 7 in a row x 3 high 120x120mm | |
| A + A + A x 8: 24 openings, 8 in a row x 3 high 120x120mm | |
| Part Number | Description |
| Part NumberA x 1 | DescriptionA x 1: 1 opening, 120 x 120 |
| Part NumberA x 2 | DescriptionA x 2: 2 openings side by side, 120 x 120mm |
| Part NumberA x 3 | DescriptionA x 3: 3 openings side by side, 120x120mm |
| Part NumberA x 4 | DescriptionA x 4: 4 openings side by side, 120x120mm |
| Part NumberA x 5 | DescriptionA x 5: 5 openings side by side, 120x120mm |
| Part NumberA x 6 | DescriptionA x 6: 6 openings side by side, 120x120mm |
| Part NumberA x 7 | DescriptionA x 7: 7 openings side by side, 120x120mm |
| Part NumberA x 8 | DescriptionA x 8: 8 openings side by side, 120x120mm |
| Part NumberA + A | DescriptionA + A: 2 openings on top of each other 120x120mm |
| Part NumberA + A x 2 | DescriptionA + A x 2: 4 openings, 2 in a row x 2 high 120x120mm |
| Part NumberA + A x 3 | DescriptionA + A x 3: 6 openings, 3 in a row x 2 high 120x120mm |
| Part NumberA + A x 4 | DescriptionA + A x 4: 8 openings, 4 in a row x 2 high 120x120mm |
| Part NumberA + A x 5 | DescriptionA + A x 5: 10 openings, 5 in a row x 2 high 120x120mm |
| Part NumberA + A x 6 | DescriptionA + A x 6: 12 openings, 6 in a row x 2 high 120x120mm |
| Part NumberA + A x 7 | DescriptionA + A x 7: 14 openings, 7 in a row x 2 high 120x120mm |
| Part NumberA + A x 8 | DescriptionA + A x 8: 16 openings, 8 in a row x 2 high 120x120mm |
| Part NumberA + A + A | DescriptionA + A + A: 3 openings on top of each other 120x120mm |
| Part NumberA + A + A x 2 | DescriptionA + A + A x 2: 6 openings, 2 in a row x 3 high 120x120mm |
| Part NumberA + A + A x 3 | DescriptionA + A + A x 3: 9 openings, 3 in a row x 3 high 120x120mm |
| Part NumberA + A + A x 4 | DescriptionA + A + A x 4: 12 openings, 4 in a row x 3 high 120x120mm |
| Part NumberA + A + A x 5 | DescriptionA + A + A x 5: 15 openings, 5 in a row x 3 high 120x120mm |
| Part NumberA + A + A x 6 | DescriptionA + A + A x 6: 18 openings, 6 in a row x 3 high 120x120mm |
| Part NumberA + A + A x 7 | DescriptionA + A + A x 7: 21 openings, 7 in a row x 3 high 120x120mm |
| Part NumberA + A + A x 8 | DescriptionA + A + A x 8: 24 openings, 8 in a row x 3 high 120x120mm |
